ONESIA Video Matrix Controller 24U (HDMI 144 In 144 Out)

Jenis Produk : TKDN AV Switch
Deskripsi : Feature Images Splicing, Matrix Switch, Input Channels support HDMI/DVI/SDI Board Card, Output Channels support DVI/HDMI Board Card, Image Segmentation, Map Mode (Ultra High Resolution Overlay Display of Static Image), Automatic Detection, Support H.264
Spesifikasi Teknis : 24U Chassis Video Processor Included HDMI 144ports IN & 144ports OUT, Maximum Input 144ports (36Slots), Maximum Output 144ports (36Slots), Network Control, RS232 Communication

Lokasi Pembelian

ONESIA Video Matrix Controller 24U (HDMI 144 In 144 Out)

Video Matrix Controller 24U (HDMI 144 In 144 Out) adalah perangkat pengelola video canggih dengan 144 port HDMI input dan 144 port HDMI output, mendukung format HDMI, DVI, dan SDI. Dilengkapi dengan fitur splicing gambar, matrix switch, segmentasi gambar, dan mode peta untuk tampilan overlay resolusi tinggi. Dukung H.264, deteksi otomatis, serta pengendalian jaringan dan komunikasi RS232. Power consumption 350W, suhu operasi -10°C hingga 50°C, dan kelembaban 5% hingga 95% tanpa kondensasi, cocok untuk aplikasi pengelolaan video skala besar.

Spesifikasi

SKU

VMX24-HDCDC-0000

Brand

ONESIA

Jenis Produk

TKDN AV Switch

Deskripsi

Feature Images Splicing, Matrix Switch, Input Channels support HDMI/DVI/SDI Board Card, Output Channels support DVI/HDMI Board Card, Image Segmentation, Map Mode (Ultra High Resolution Overlay Display of Static Image), Automatic Detection, Support H.264

Spesifikasi Teknis

24U Chassis Video Processor Included HDMI 144ports IN & 144ports OUT, Maximum Input 144ports (36Slots), Maximum Output 144ports (36Slots), Network Control, RS232 Communication

Keterangan Lainnya

Power Consumption 350W, Operating Temp -10 ~ 50°C, Relative Humidity 5 - 95 No Condensation

Chassis

24U Chassis

Ports Input

144 HDMI ports (36 Slots max)

Ports Output

144 HDMI ports (36 Slots max)

Max Input

144 ports

Max Output

144 ports

Network Control

Supported

Communication Interface

RS232

Image Segmentation

Supported

Map Mode

Ultra High Resolution Overlay Display of Static Image

Automatic Detection

Supported

Video Format Supported

HDMI/DVI/SDI Board Card for Input & Output Channels

Supported Codecs

H.264

Power Consumption

350W

Operating Temperature

-10 ~ 50°C

Relative Humidity

5 - 95% (No Condensation)

Energy Efficiency

Not rated

Country of Origin

Not specified
