SKU

· RA-20-3

Brand

· ONESIA

Kategori

· UPS

Capacity

· 20kVA

Spesifikasi Teknis

· ± 5 - 15 menit

Waktu Pemindahan

· 0ms

Battery Capacity

· VRLA/SLA

Waktu Pengisian Baterai

· 4-8 Hours

Garansi

· 3 Tahun

Rated AC Voltage

· 380V / 400V / 415V AC (3Ph+N+PE)

Input Voltage Range

· 290V ~ 480V AC ± 5V

Input Frequency Range

· 50 / 60 Hz ± 10% Auto Sensing

Power Factor

· ≥ 0.99

Walk-in Time

· 5 ~ 300 Sec. (Configurable)

Bypass Rated Voltage

· 380V / 400V / 415V AC (3Ph+N+PE)

Bypass Voltage Range

· =+ 20%, -30% (Configurable)

Bypass Frequency Range

· 50 / 60 Hz ± 10% (Configurable)

Battery Voltage

· 384V DC Standard (360 ~ 408 Configurable)

Ripple

· ≤ 1%

Charging Current Max. (A)

· 0.10C to 0.25C up to 100~300Ah at 100% Load (Configurable)

Output Rated Voltage

· 380V / 400V / 415V AC (3Ph+N)

Frequency Range

· Auto Sensing 50 / 60 Hz ± 1~10% Sync Mode (Configurable), 50/60 Hz ± 0.1 Hz Battery Mode

Voltage Regulation

· ±1%

Harmonic Distortion (THDv)

· ≤ 1% Linear Load, ≤ 5% Non-Linear Load

Efficiency

· Up to 95% Dual Conversion Mode, 99% ECO Mode

Overload

· ≤ 110% for 60 Min, ≤ 125% for 10 Min, ≤ 150% for 1 Min, ≥ 150% for 300 ms

Display

· Touch Screen & LED Mimic Diagram

IP Rating

· IP 20

Temperature

· Operating: 0~45°C, Storage: -10ºC ~ 55ºC

Humidity / Altitude

· 0~95% RH Non-condensing / <1500 M
